Hauser S-50 DR - CNC Jig Grinder - $45,000 - (Scottsdale, AZ)
Machine Tools 24/7 - 352-799-8398 Hauser S-50 DR CNC Jig Grinder Fanuc 18M Control Capacity: Table Length x Width 40.125" x 28.25" Maximum Table Load 2,800 Lbs Travels: X-Axis Travel 35.4" Y-Axis Travel 23.6" Z-Axis Travel (Rail Travel) / Quill 31.4" / 7" Distance Grinding Spindle to Table / Between Columns 29.5" / 37.4" Grinding Wheel: Ground Diameter / Without Extention Plate / With 3.937" / 9.1" / 14.17" Taper Grinding 16° Spindle: Planetary Spindle Speeds / Grinding Spindle 5 - 250 / 160,000 RPM Spindle Diameter 3.937" Tool Changer: Tool Changer Positions 8 ATC Traverse: Rapid Traverse X & Y / W 6 - 295 / 78.74 IPM Feeds: Feeds X & Y / W 70.86 / 31.5 IPM Dimensions: Floor Space Machine (L x W x H) 122" x 84" x 122" Control Cabinet (L x W x H) 64" x 20" x 80" Weight (approx. a;;) 15,000 Lbs Additional Info.: Hardened Bed Ways Hauser Jig Grinding Head Coolant System Note: From Large Aerospace Facility Was Operational When Removed From Service - As-Is-Where-Is
